+ W42LS-7X

W42LS-7X

42" 7-Drawer Roll-Wagon
Fully Shelf-Closing, Ball Bearing Slides
One Drawer Open at a Time Locking System

  • Fully shelf-closing ball bearing slide .

  • Large diameter surface covered handle,excellent sensible touching .

  • 6"x2" heavy duty roller Column caster.(2 swiVel+2 Swivel With brake )

  • Protecting top of surface with 15mm thick particle board on top of roll-wagon .

  • One piece steel of cabinet body provide more strength to whole one unit body structure .

  • 100 numbers internal locking system for extra security .

  • Quick release design on ball bearing slide can be easily removed for replacement .

  • 100% open ball bearing slide .

  • Strengthen lower part under large drawer,Can be Ioaded with extra large size tools capacity .

  • Patented locking system , pushing unlocked drawer to be locked while all others are locked .

  • Drawers are interchangeable .

  • Four fixture on two sides,can be attached and hung other equipments .

  • Powder coating finishing .

  • Hemmed edge for aII drawers and body to add strength and safety .

  • 2mm protective drawerliners .

Function

Steel thickness:

Top and bottom covers:1.5mm

Body:1.2mm

Drawer:1.0mm

M267303(TW)

M282635(TW)

766086(CN)

Nr.202005000374.3

ADDRESS /

No.9, Chung-Chien RD, Shen-Kang Dist, Taichung City, Taiwan

E-Make

TEL / 886-4-25633456

FAX / 886-4-25615982

E-mail / sales@e-make.com.tw
